Quadcopter Build Diary – Part 1 – Parts
Having fallen in love with a new hobby after plenty of time playing with my first quadcopter I decided it was time for an upgrade. After some thought about what I’d like from this new quad I came up with some rough criteria.
- Not pre-built
- Able to carry a go pro
- Eventually be able to add first person view functionality
- Not cost a fortune!
Nothing too restrictive here. Basically I wanted something that would give me lots of chances to learn during this project while also being future proof. These are the parts I came up with (and their rounded current costs)
Parts
- Frame – Hobbyking X525 V3 Glass Fiber 600mm – £9
- Motors – 4 x NTM Prop Drive 28-26 1100kv / 252w – 4 x £9 – £36
- Motors Accessories – 4 x NTM Prop Drive 28 Accessory Pack – 4 x £1 – £4
- ESC – 4 x 30A Blueseries Brushless Speed Controller – 4 x £8 – £32
- Props CW – 3 x 9047 Turnigy Slow Fly Propeller CW Orange = 3 x £1 = £3
- Props CCW – 3 x 9047 Turnigy Slow Fly Propeller CCW Orange = 3 x £1 = £3
- Flight Controller – MultiWii NanoWii Micro Flight Controller – £13
- Power Distribution Board – Hobbyking Power Distribution Board – £3
- Battery – Multistar High Capacity 3S 4000mAh Multi-Rotor Lipo – £16
- Charger – Hobbyking B3AC Compact Charger – £4
- Transmitter/Receiver – Turnigy 9X – £40
Total: £163
And here they all are with the frame already assembled.
(click for larger)
